Maternal ASUS PRIME X570-PRO board

Description Maternal ASUS PRIME X570-PRO board

Motherboard for AM4 AMD processors: ATX form factor, the bus PCIe 4.0, the 14-phase power system with the modules DrMOS, DDR4-4400, two slots of M.2, Gbps HDMI, SATA 6, frontal Gen2 USB interface 3.2, illumination with synchronization of Aura Sync

• AM4 Connector for AMD Ryzen processors of the third and second generations
• Optimized power system: the scheme 12+2 phases, the power DrMOS modules, ProCool connectors, high-quality element base
• 5-sided optimization of the computer one mouse click
• Intelligent cooling system with adjustment of fans and water pumps via the Fan Xpert 4 utility or the UEFI BIOS interface
• Radiator for cooling of the M.2 solid-state drive installed in the slot
• OptiMem Technology: the optimized distributing of slots for increase in frequency potential of memory modules
• Modern interfaces: PCIe 4.0, two slots of M.2, USB 3.2 Gen2 (including the connector for case USB port)
• Built-in color illumination of Aura expanded by means of LED tapes and synchronized with other Aura-compatible devices

Allocated with professional appearance and the balanced technical characteristics, motherboards of the Prime X570 series are intended for all who want to use Ryzen processors for productive work. In them the set of exclusive functions of ASUS, including a wide choice of means for setup of performance of the computer is implemented.

Reliable base for the PC

Stable power, easy cooling in setup, modern interfaces – motherboards of the Prime X570 series offer the user all necessary fundamental things which will allow to use with the maximum effect the latest Ryzen processor in daily work.

ProCool Connectors

8- and 4-contact ProCool connectors connect the 12-voltny bus of the power supply directly to the processor. Thanks to integral, but not hollow contacts they are capable to carry current of bigger force, than normal.

Power DrMOS modules

In the Prime X570-P power system implemented according to the scheme of 8+4 phases of power the power MOS Dr. modules, each of which includes the driver and also MOSFET keys of the upper and lower shoulder. Thanks to such component integration the increased power system efficiency is reached.

Floatable throttles

Powerful power system implemented on payments of the Prime X570 series for support of the latest AMD processors requires appropriate cooling therefore on its components the big radiator with the highly effective thermointerface is used.

Durable condensers

In motherboards of ASUS perfect condensers which are capable to work longer and under more difficult conditions, than standard.

6-layer printed circuit board

Multilayered pc board design facilitates heat extraction from components, thereby increasing the frequency potential of the processor at acceleration.

Two connectors M.2 (PCIe 4.0)

Thanks to existence of two connectors M.2 designed for format devices up to 22110 and working in the PCIe 4.0 mode, the user can not only connect modern solid-state drives at a high speed, but also integrate them in the RAID.

Strengthened fastening of slots of PCIe

SafeSlot is the design of slots of PCIe developed by ASUS which differs in the improved durability and provides the strengthened video card clip. Such slot is made with use of new process of formation with an insert during which the metal framework is integrated into it. It strongly fixes the slot on the motherboard by means of additional points of soldering.

High-speed ports USB 3.2 Gen 2 (10 Gbps)

Motherboard is equipped with Gen 2 Type-A USB 3.2 port and symmetric port USB 3.2 Gen 2 Type-C, guaranteeing backward compatibility with the devices possessing the USB interface of the previous versions and the maximum throughput of 10 Gbps.

In the Prime X570-Pro motherboard by

comfortable support of USB interface 3.2. The user gets advantages of this high-speed port on the front panel of the system unit.

Network controller of Intel

Network controllers of Intel are famous for the stable and effective work at the low level to loading of the CPU. The Ethernet controller used on the motherboard provides the high speed of processing of packages of TCP and UDP.

LANGuard Technology

Connector of a wired network on this motherboard is equipped with special protection against static and differences of tension.

Tracking several thermal sensors

Each ventilatory connector can obtain data from several (to three) thermal sensors. Moreover, the Fan Xpert 4 utility allows to trace temperature of compatible video cards of ASUS and to use it as basis for adjustment of system fans.

I Will corrode

for connection of high-performance water pumps (more than 3 And, adjustment on PWM or tension) and also I will corrode for end-to-end systems of water cooling.

Connectors of 4-contact fans

Each ventilatory connector of a payment supports by

automatic detection of type of the fan (with adjustment on PWM or tension).

Automatic protection

by

for protection of all ventilatory connectors against overheating and overcurrent condition.

chipset Radiator with the fan

Bus PCIe 4.0 increases the volume of data processed by a chipset that finally leads to increase in its temperature. That is why on the Prime X570-P board the chipsetny radiator is complemented with the separate fan.

Active cooling includes the components given below.

1. Air duct. Specially developed air duct helps the fan to create static pressure and to strengthen the air flow passing between radiator fins.
2. Radiator with edges. Radiator fins have such density at which the maximum area of heatdispersion and low resistance to the coming-out air is provided.
3. Special Delta Superflo fan. The quiet fan which is specially manufactured for this payment has the high-strength bearing with nominal durability (L10) at 60,000 oclock.

Radiator of M.2

Drives of format M.2 are located under radiators of passive cooling that minimizes the probability of falling of performance of SSD because of a temperature trottling and provides superfast data transmission.

Fascinating sounding

Thanks to in Prime X570-Pro of the unique Realtek S1220A audiocodec the binaural sound on a linear audio output of a payment has an unprecedented ratio a signal noise (SNR) 120 dB, and the SNR level on a linear input is 113 dB. Besides, the special scheme on a payment automatically determines resistance of the connected earphones for setup of an optimum gain amount.

Flexible setup

In the interface of a firmware of motherboards of the Prime X570 series and in the utilities attached to them is available a set of in-out parameters by means of which it is possible to make setup and optimization of the computer that that worked exactly as it is necessary for you.

Low energy consumption

Special EPU processor automatically determines extent of loading of a system and optimizes its energy consumption. It supports a particular treatment with the lowered energy consumption.

with

management of power supply parameters in real time and allows to configure precisely operation of the voltage controller of the CPU for ensuring the maximum stability and system performance.

Friendly interface

Motherboards of the Prime X570 series are allocated with

convenient in use and the functional UEFI BIOS interface.

Armoury Crate

Armoury Crate Application represents uniform control center of products of ASUS. The different settings connected with illumination and hardware parameters are presented in its intuitive interface. Besides, there are special sections for viewing news from ASUS and registration of the bought devices.

Aura Illumination

Serious tuning of system performance deserves also the corresponding esthetics. Motherboards of this series are equipped with the built-in system of illumination of Aura with flexible adjustment of parameters. Besides, it is possible to connect additional LED tapes to them and to synchronize visual effects with other Aura-compatible devices of ASUS. (* It is possible to connect LED tapes of format 5050 RGB with current to 3 A to the RGB connector (12 V). The maximum brightness is reached when length of a tape does not exceed 3 m ** extenders for not addressed LED tapes are included In the package of delivery. LED tapes and Aura-compatible devices are on sale separately.)

I Will corrode

for the addressed LED tapes, used on the Prime X570-Pro motherboard, it is capable to define quantity of LEDs on the addressed tapes of the second generation that allows the software to configure automatically lighting effects for specific devices. New connectors also provide backward compatibility with the existing devices supporting Aura illumination.

Chipset and the processor

Chipset of AMD X570 supports by

16 PCIe 4.0/3.0 lines, Gen2 USB 3.2 ports (10 Gbps) and SATA of 6 Gbps for connection of peripheral devices and also provides ample opportunities on acceleration of AMD processors for the AM4 connector. Besides, it is optimized under use of the multiprocessor graphic configurations collected on NVIDIA SLI or AMD CrossFireX technologies.

AM4 Connector for AMD processors

This motherboard is compatible

AMD Ryzen processors (3rd and 2nd generations) and Ryzen with a graphic kernel of Radeon Vega (2nd and 1st generations) which are installed in the AM4 connector. Containing up to 16 kernels made on technology of 7 nanometers, models of the Ryzen series of the 3rd generation embody innovative microarchitecture of Zen. AMD processors for the AM4 connector support Gen2 USB interface 3.2 (10 Gbps), 16 PCI Express 4.0/3.0 lines and two-channel random access memory of DDR4.
